Schenker SMART 30 User Manual

4 – MOUNTING AND INSTALLATION COD.30S12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia - ALL RIGHTS RESERVED
22
4.3.3 Fresh water intake for washing
Fresh water
intake for
washing
Tee in downstream of the vessel's fresh water
pressure system.
The following conditions must be respected:
• The flow of the existing fresh water pump
must be min 6 lit/min.
• Flushing must always be performed with
the pressure water system ON.
Pressurized tank: Min. flow rate
must be 6 lit/min. at 2,5 bar.
CAUTION
Pressurized tank: Min. flow rate must be 6 lit/min. at 2,5 bar.
4.3.4 Brine discharge
Salt water
discharge
The salt-water drain shall be ½’’ minimum size
and it has to be preferably above the seawater
level.
Minimum size ½’’
Pre-existing salt
water discharge
(alternatively)
It is possible to use offtakes from existing
apparatuses, provided that:
• It is not the engine cooling water drain or
apparatuses that drain out water with
elevated pressure.
INSTALLATION NOTES
If the discharge is upon the seawater level, it is recommended to provide a valve along the pipe.
CAUTION
Do not run the system when the discharge valve is closed.
