Scheppach HS100S Translation Of Original Instruction Manual

www.scheppach.com
GB
|
27
Table of contents: Page:
1. Introduction ........................................................................................................ 28
2. Device description ............................................................................................. 28
3. Unpacking .......................................................................................................... 28
4. Intended use ...................................................................................................... 29
  .............................................................................................. 30
6. Technical Data ................................................................................................... 35
7. Before starting the equipment ........................................................................... 35
8. Attachment and operation ................................................................................. 35
9. Using the saw .................................................................................................... 37
10. Operation ........................................................................................................... 38
11. Transport ............................................................................................................ 39
12. Maintenance ...................................................................................................... 39
13. Storage .............................................................................................................. 39
14. Electrical connection ......................................................................................... 39
  ....................................................................................... 40
16. Troubleshooting ................................................................................................. 41

Scheppach HS100S Specifications

General

Blade bore	30 mm
Blade diameter	250 mm
Number of teeth	24
Idle speed (max)	5000 RPM
Cutting depth (90º)	-, 85 mm
Maximum cutting height	85 mm
Saw blade included	-
Height adjustment range	0 - 85 mm
Input power	2000 W
AC input voltage	220-240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	940 mm
Width	780 mm
Height	1100 mm
Weight	19400 g
Bench depth	485 mm
Bench width	642 mm
