www.scheppach.com
GB
|
35
7. Before starting the equipment
• The equipment must be set up where it can stand se-
legs for this.
•
•
• When working with wood that has been processed
before, watch out for foreign bodies such as nails
or screws, etc.
•
• -
-
cal to the mains data.
• -
tive contact socket, with at least 16A circuit breaker.
8. Attachment and operation
Important! Pull out the power plug before carrying
out any maintenance, resetting or assembly work
on the circular saw.
equal parts.
Note: If compounds with a bolt (round head / or hexa-
gon), hex nuts and washers are backed up, the washer
Insert screws each from outside to inside. Secure con-
nections with nuts on the inside.
Note:
8.1 Mounting the bench extension (g. 5)
1.
bench facing down.
2.
bench (1).
3. Push table extension (8) onto the sawing table (1)
using the hex bolts (19) and cross member (21c).
Repeat for the opposite side.
6. Technical Data
AC motor 220-240 V~ 50Hz
Performance S1 1800W
Operating mode S6 25% 2000W
Idle speed 5000 min
-1
Hart-metal blade ø 250 x ø 30 x 2,8 mm
Number of teeth 24
Thickness riving knife 2 mm
Table size 563 x 583 x 28 mm
Cutting height max. 90° 85 mm
Cutting height max. 45° 65 mm
0 - 85 mm
Saw blade swivel 0 - 45°
Suction port ø 35 mm
Weight ca. 19 kg
* Operating mode S6 25%: Continuous operation
with intermittent loading (playing time 10 min). En-
gine protection of to hot warming up:
It´s allowed to run the engine with nominal power
maximum 25% of playing time. After this the ma-
chine must run 75% of playing time steadily with-
out load.
Noise values
The total noise values determined in accordance with
EN 62841.
Sound pressure level L
pA
94,0 dB(A)
K
pA
3 dB
Sound power level L
WA
107,0 dB(A)
K
WA
3 dB
Wear hearing protection.
vibration values (vector sum - three directions) deter-
mined in accordance with EN 62841.
