Device emissions values
Noise
The noise levels have been determined in accordance
with EN 61029.
Wear hearing protection.
Excessive noise can result in a loss of hearing.
Sound pressure level L
pA
66,9 dB(A)
Uncertainty K
pA
3 dB
Sound power level L
WA
79,9 dB(A)
Uncertainty K
WA
3 dB
Vibration emission value
• The specied vibration emission value has been
measured according to a standardised testing pro-
cedure and can be used for comparison of one elec-
tric tool with another;
• The specied vibration emission value can also be
used for an initial assessment of the (vibration) load.
• The vibration emission value can vary from the
specied value during the actual use of the electric
tool, depending on the type and the manner in which
the electric tool is used;
A warning:
• It is necessary to determine the safety measures for
the protection of the operator based on an assess-
ment of the vibration load during the actual condi-
tions of use (In doing so, all parts of the operating
cycle must be taken into account such as times in
which the electric tool is switched off or times in
which it is switched on, but is not running under a
load).
The stipulated values are emission values and so do
not necessarily represent safe work station values. Al-
though there is a correlation between emission levels
and exposure levels, it is not possible to reliably deter-
mine whether additional precautionary measures will
be required or not based on this.
Factors that could inuence the emissions level pres-
ent at any given time at the work station include the
duration of exposure, the nature of the working area,
other noise sources etc. e.g. the number of machines
and neighbouring processes.
• Do not switch on the saw until the work table is
cleared of material residues and tools. Only leave
the workpiece to be machined and any work aids
(wedges) on the workbench.
• Always wear safety goggles.
• Keep ngers at a safe distance from the saw blade.
• Guide the workpiece securely and rmly and do not
let it loose at any point.
• Never leave the work station without setting down
the saw beforehand.
• Do not let your familiarity with the saw lead you to
carelessness. Carelessness can lead to serious in-
juries in a split second.
Store the safety instructions safely.
6. Technical data
Mains voltage 220-240 V~/50 Hz
Power consumption 80 Watt (S1*)
120 Watt (S6 30%**)
Stroke rate 500-1700 rpm
Lifting movement 12 mm
Base 630 x 295 mm
Tilting table 0° to 45° to the left
Table size 415 x 255 mm
Saw blade length approx. 134 mm
Swing 406 mm
Cutting height max. at 0° 50 mm
Cutting height max. at 45° 22 mm
Weight 12.7 kg
*Operating mode S1:
Continuous operation at constant load
**Operating mode S6 30%:
Continuous duty with intermittent loading (operating
time 10 mins). In order avoid impermissible overheat-
ing of the motor, the motor should be driven for only
30% of the operating time with the stipulated nominal
power and must then continue to run with no load for
the remaining 70% of the operating time.

Scheppach sd1600v Specifications

General

Blade length	134 mm
Throat depth	406 mm
Product color	Black, Blue
Stroke height	50 mm
Idle speed (max)	1700 RPM
Idle speed (min)	500 RPM
Table tilt range	0 - 45 °
Maximum power	120 W
AC input voltage	220-240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	630 mm
Width	295 mm
Height	370 mm
Weight	12700 g
Table depth	415 mm
Table width	255 mm
