15. Troubleshooting
m WARNING
Always switch the machine off and remove the mains plug prior to all maintenance and cleaning work.
Fault Possible cause Remedy
Saw blade without pins
loosens after switching
off the engine
Saw blade clamping screw (27/28) not
tightened enough
Tighten the saw blade clamping screw
(27/28)
Motor does not start Mains fuse blown Check mains fuse
Extension cable defective Replace the extension lead
Fine-wire fuse defective Check the ne-wire fuse and, if
necessary, replace it with a ne-wire
fuse of the same type.
Connection to the motor or switch not OK Have this checked by an electrician
Motor or switch faulty Have this checked by an electrician
Saw blades brake Tension set incorrectly Set correct tension
Load too high Feed workpiece more slowly
Incorrect saw blade type Use correct saw blades
Workpiece not fed straightly Avoid lateral pressure
Saw blade oscillates, not
aligned straightly.
Holders not aligned Open the screws that fasten the holders.
Bring the holders into the vertical posi-
tion and tighten the screws again.

Scheppach sd1600v Specifications

General

Blade length	134 mm
Throat depth	406 mm
Product color	Black, Blue
Stroke height	50 mm
Idle speed (max)	1700 RPM
Idle speed (min)	500 RPM
Table tilt range	0 - 45 °
Maximum power	120 W
AC input voltage	220-240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	630 mm
Width	295 mm
Height	370 mm
Weight	12700 g
Table depth	415 mm
Table width	255 mm
