schildknecht DATAEAGLE COMPACT 4 Series - Example 1: Exchange of a Radio Slave

Installation and commissioning DATAEAGLE 4XXX Compact 5-23
Overview
Connect Radio
Master to Wizard
Chapter 5 – Extension and exchange
5.3.6. Example 1: Exchange of a Radio Slave
Connect Radio Master to Wizard

Read off Radio Master address

Determine address of the exchanged Radio Slave

Connect Radio Slave to Wizard

Enter Radio Master and Radio Slave address

Enter channel or Bluetooth MAC Address

Connect the Radio Master with the USB cable to the
PC.
