Installation and commissioning DATAEAGLE 4XXX Compact 4-1
Chapter 4 – Installation of new devices
4. Installation of new devices
Please be certain to read the guidelines in chapter 7
„Tips and Tricks – improvement of the electromagnetic
compatibility (EMC)“. Observe these guidelines during
the complete installation procedure. Thereby you avoid
electromagnetic interferences and you improve the data
transmission quality.
New devices are pre-configured in the factory.
Further settings are not necessary.
4.1. Overview Installation
The installation is very easy and is carried out according to
the procedure shown below:
Install module on top-hat rail
In case of limited space in the control cabinet:
Connect the power supply before you install the unit on
the top-hat rail.
