schildknecht DATAEAGLE COMPACT 4 Series - Example 2: Exchange of a Radio Master

Installation and commissioning DATAEAGLE 4XXX Compact 5-30
Overview
Chapter 5 – Extension and exchange
5.3.7. Example 2: Exchange of a radio master
Connect Radio Slave to Wizard

Read off Radio Master and Radio Slave addresses

Exchange of Dataeagle
43XX
(869 MHz)
Exchange of Dataeagle
47XX
(Bluetooth)
Read off channel
Connect Radio Master to
Wizard


Connect Radio Master to
Wizard
Enter Radio Master and all
Radio Slave address


Enter Radio Master and all
Radio Slave address
Read off Bluetooth MAC Ad-
dress


Enter channel
Adapt filter time if necessary
(Profinet / openSAFETY)

Adapt filter time if necessary
(Profinet / openSAFETY)
Connect Radio Slaves to
Wizard

Enter Bluetooth MAC Ad-
dress into all Radios Slaves
