Automatic Mode (ECG) Settings (cont.)
Selecting Rhythm Leads
The rhythm leads are printed out as defined. Two separate rhythm leads can be selected. The
following formats can be set:
Rhythm Leads (interpretation option
only)
Entry Key
Sequence
Setup Format
ALT
3 Define Rhythm lead one
4 Define Rhythm lead two
The 2 rhythm leads are defined as follows:
Extremity Leads
Entry Key Sequence Lead Confirm
ALT
3 or
4
8
1 I
Press
STOP
key
2 II
3 III
4 aVR
5 aVL
6 aVF
Precordial Leads
Entry Key Sequence Lead Confirm
ALT 3 or 4 9
1 V1
Press
STOP key
2 V2
3 V3
4 V4
5 V5
6 V6
Confirm the selection by pressing the STOP key
STOP
