Connecting the light guide
The multi-light-guide connector enables the connection of light guides supplied by
different manufacturers.
Original light guides from Karl Storz, Richard Wolf and Olympus can be attached
directly without adapters. Light guides of other manufacturers than that must be
used with the corresponding light guide adapters.
Proceed as follows:
WARNING! High-intensity light. Risk of injury to eyes. Do not look directly into
the open end of the light guide.
1. Slide the light guide into the multi-light-guide adapter until it clicks into place,
as far as it will go.
The light exits the distal end of the light guide.
The light guide is connected.
4.6 Decoupling the Light Guide
Decoupling the light guide
Proceed as follows:
1. Rotate the multi-light-guide adapter clockwise as far as it will go.
The light guide detaches.
The LED switches off, the device remains switched on.
2. Pull out the light guide.
3. Detach the adapters used, and arrange for reprocessing the light guide.
Observe the instructions for use supplied with the light guide.
The light guide has been decoupled.
