Schuler HF255 - Page 43

- 11 -
HF255, HF295 AXLE
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
0-260250
AXLE ASSEMBLY WELDMENT, HF255
1
0-260240
AXLE ASSEMBLY WELDMENT, HF295
2
2
2022A-0180
SPINDLE ASSY, HF255
2
2024P-0198
SPINDLE ASSY, HF295
3
2
180CR26260
GREASE SEAL, 2.63 ID * 3.63 OD
2
180CR27541
GREASE SEAL, 2.75 ID * 4.003 OD
4
2
18LM104949
BRG CONE, INNER 2 BORE
2
180387AS-N
BRG CONE, INNER HF295
5
2
18LM104912
BRG CUP, INNER
2
180000382A
BRG CUP, INNER HF295
6
2
1922A-0800
WHEEL HUB 8-BOLT, W/CUPS, CONES, SEALS & BOLTS
2
1924A-0801
WHEEL HUB 8-BOLT, 8000 LB, CONES, 2 3/4" SEALS & STUDS
7
2
1800025821
BRG CUP, OUTER
2
18LM501310
BRG CUP, OUTER HF295
8
2
1800025877
BRG CONE, OUTER 1 3/8 BORE
2
18LM501349
BRG CONE, OUTER HF295
9
2
2007P-0002
SPINDLE WASHER, 15/16 ID * 2 OD
2
2008P-0002
SPINDLE WASHER, 1 1/16 ID * 2 1/8 OD * 1/4 THICK
10
2
2007P-0001
SPINDLE NUT, 7/8-14 SLOTTED
2
2008P-0001
SPINDLE NUT, 1-14 SLOTTED NUT
11
2
2007P-0000
SPINDLE COTTER, 5/32 * 1 1/4
2
2008P-0003
SPINDLE COTTER, 7/32 * 1 1/2
12
2
1917P-0003
CAP, 6-BOLT HD, & 8-BOLT HUB
2
1924P-0003
CAP, 8-BOLT HD (8000 LB)
13
16
1917P-0001
WHEEL BOLT, 9/16-18 * 1 1/8, GRD 5, ZP
16
1924P-0002
WHEEL STUD 5/8-18 NF (8,000 LB)
14
2
2108P-0822
WHEEL 8-BOLT, 22.5 * 8.25, 5/8 HOLES
2
2108P-0820
WHEEL 8-BOLT, 22.5 * 8.25, 5/16 DISH, 5/8 HOLES, 8000 LB
15
2
2100T-2208
TIRE 295 75R-22.5, ULTIMA LCT RECAP
2
2100T-2212
TIRE, 315/80R22.5 ECLIPSE MUD & SNOW RECAP
16
16
1924P-0005
WHEEL NUT 5/8-18 NF FLANGE NUT
17
2
70HC5-1048
5/8-11 * 6 HHCS GRD 5, ZP
2
70HC5-0840
1/2-13 * 5 HHCS, GRD 5, ZP
18
2
71UC2-0100
5/8-11 TOP LOCKNUT, ZP
2
71UC2-0080
1/2-13 TOP LOCKNUT, ZP
19
4
72FH0-0100
5/8 FLAT WASHER, ZP
4
72FH0-0080
1/2 FLAT WASHER, ZP
