- 13 -
PTO INPUT SHAFT AND DRIVE HF255
ITEM
QTY
PART NUMBER
DESCRIPTION
1
8
71RC2-0100
5/8-11 NUT, ZP
2
5
72LH0-0100
5/8 SPLIT LOCK WASHER, ZP
3
A/N
72M10-0014
MACHINE BUSHING, 5/8 ID * 1 1/8 OD * 14 GA, ZP
4
2
13070-1C06
FLAT IDLER, C-BELT, 7 OD, 5/8 BORE
5
4
70HC5-1020
5/8-11 * 2 1/2 HHCS, GRD 5, ZP
6
1
37E08-H070
SPRING EXTENSION, 1 OD X 7 LONG
7
1
72FH0-0100
5/8 FLAT WASHER, ZP
8
1
0-101500
IDLER, PULLEY TIGHTENER ARM
9
1
71EC2-0100
5/8-11 JAM NUT W/NYLON INSERT, GRD 2, ZP
10
1
0-300510
ANGLE BRACKET WITH WELDED 5/8-11 * 2 1/2 BOLT
11
1
13070-1C05
V-BELT IDLER, C-BELT, 7 OD, 5/8 BORE
12
1
1501C-1360
V-BELT, C-136
13
1
70HC2-0648
3/8-16 * 6 HHCS, GRD 2, ZP
14
1
17202-1208
FLANGE BRG, 1 B, 52MM lll LIP, W/65 ANGLE ZERK, 52MM PLAIN
15
1
73E00-0416
1/4 * 2 SPRING PIN, ZP
16
1
0-152000
SHAFT, POWER INPUT, 1 CRR * 8 1/4, 1/4 KW & 3/8 PH
17
1
12050-1001
CHAIN #50, 100 P, W/CL
18
1
0-411012
PTO ALIGNMENT PULLEY & SPROCKET HF 1 B 1/4 KW
19
1
0-411011
PTO ALIGNMENT PULLEY DRIVER, 1 B, 1/4 KW
20
1
0-130212
KEY, 1/4 CD * 1 1/4
21
1
0-153001
BRACKET, POWER INPUT, PTO, FOR HF255
22
1
73S00-0616
3/8 * 2 SPIROL PIN, HBK
23
1
17200-1208
FLANGETTE BRG,1 B, 52MM, 2 SS W/ 2 FLANGES
24
1
0-260045
BRACKET, ROLLER CHAIN TIGHTENER, W/(2) 1/2-13 NUTS, 11 1/2
25
2
11050-1705
CHAIN IDLER #50, 17 T, 5/8 BORE
26
1
0-153500
BRACE, POWER INPUT BRACKET, 7 GA * 1 * 19 1/2
27
1
0-272500
PTO RUBBER COVER GUARD, 1/8 RUBBER * 6 * 18
28
1
0-260173
PTO SHIELD, 16 GA * 7 1/2 * 16 3/4
29
1
70HC5-1036
5/8-11 * 4 1/2 HHCS GRD 5, ZP
