- 25 -
CROSS CONVEYOR WITHOUT FOLD-UP EXTENSION
ITEM
QTY
PART NUMBER
DESCRIPTION
1
3
0-130201
KEY, 1/4 CD * 1 1/2
2
1
11050-2508
SPKT 50B25, 1 BORE, 1/4 KW, 2SS
3
4
17203-1208
FLANGE BRG, 1 B, 52MM, W/65 ANGLE ZERK, 52MM PLAIN
4
1
0-260266
SHAFT, CROSS CONVEYOR TRANSFER, 1 CRR * 34
5
1
11050-1708
SPKT 50B17HT, 1 BORE, 1/4 KW, 2SS
6
1
12050-1732
CHAIN #50, 173 P, W/CL & OL
7
1
11050-3008
SPKT 50B30, 1 B, 1/4 KW, 2SS
8
1
0-970306
SHAFT, CROSS CONVEYOR DRIVE 1 CRR * 30 1/2, 1/4 KW
9
4
0-260139
NYLON BLOCK, ROLLER CHAIN, 1 OD UHMW * 9/32 ID * 2
10
1
0-103005
IDLER, NYLON, W/BUSHING, ROLLER CHAIN 5/8 B * 3 OD * 1 1/2
11
1
0-104005
PIVOT ARM, ROLLER CHAIN TIGHTENER
12
1
0-260085
ROLLER CHAIN TIGHTENER ASSY, 6" OAL
13
1
37C06-S036
SPRING COMPRESSION, 3/4 ID * 3 3/4 LONG
14
1
0-193155
SPACER TUBE, APRON TIGHTENER, 5/8 OD * 1/2 ID * 1 1/2
15
1
0-260178
SHIELD, REAR CROSS CONVEYOR DRIVE, W/O FOLD UP EXT
16
2
73S00-0516
5/16 * 2 SPIROL PIN, HBK
17
2
16C10-0608
SPKT CAST, 6T, 1 B, 5/16 PH
19
2
28000-0008
SET COLLAR, 1 BORE, STEEL
