Design and description
09.00 | MPG | Assembly and Operating Manual | en | 389213
19
4 Design and description
4.1 Configuration
2-Finger Parallel-Gripper
1 Housing
2 Main air connections
3 Base jaws
4.2 Description
2-finger parallel gripper with smooth roller guides on the base
jaws
