SCHUNK MPG Series - Tightening torque for screws

Maintenance
42
09.00 | MPG | Assembly and Operating Manual | en | 389213
7.5 Tightening torque for screws
Position of the item numbers Drawings [
}
42]
Tightening torque [Nm]
Item
MPG
16 20 25 32 40 50 64 80
5 - 2.2 - - - - - -
18 0.88 0.6 0.6 1.1 2.6 5.1 5.1 8.0
19 0.65 - 0.8 0.8 2.2 2.2 5.9 10.0
20 0.16 0.34 0.34 0.68 0.68 0.68 1.2 3.1
21 0.16 0.34 0.34 0.68 0.68 0.68 1.2 3.1
45 - 2.2 - - - - - -
48 0.88 0.6 0.6 1.1 2.6 5.1 5.1 8.0
49 0.65 - 2.7 2.7 4.9 4.9 10 10.0
65 - 2.2 1.3 1.3 - - - -
68 - 0.6 0.6 1.1 - - - -
7.6 Drawings
The following figures are example images.
They serve for illustration and assignment of the spare parts.
Variations are possible depending on size and variant.
