Assembly
09.00 | MPG | Assembly and Operating Manual | en | 389213
21
Ø Check the evenness of the mounting surface,
Mechanical connection [
}
22].
Ø Only open the required air connections (main connection or
direct connection), Pneumatic connection [
}
24].
Ø Connect the product via the hose-free direct connection.
✓ Use O-rings from the accessory pack.
✓ Seal main air connections which are not required with locking
screws.
Ø OR: Connect compressed air lines to the main air
connections"A" and"B".
✓ Screw in air connections (plug connections).
OR: Screw on throttle valve in order to be able to perform
sufficient throttling and/or damping.
Ø Screw the product to the machine/system,
Mechanical connection [
}
22].
✓ If necessary, use appropriate connection elements (adapter
plates).
✓ Observe the maximal tightening torque, admissible screw-in
depth and, if necessary, strength class.
Ø Secure the gripper fingers to the base jaws,
Mechanical connection [
}
22].
Ø Connect the sensor, see assembly and operating manual of the
sensor.
Ø Mount the sensor, Mounting the sensor [
}
26].
