Montage- und Betriebsanleitung für 2-Backen-Parallelgreifer
PGN-plus mit Werkzeugschnittstelle HSK/KM/Capto
Operating manual for 2-Finger Parallel Gripper
PGN-plus with tool interface HSK/KM/Capto
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
19 5509 642 Zentrierhülse / Centering sleeve Ø 8 2
20 5509 641 Zentrierhülse / Centering sleeve Ø 6 4
35 9611 054 O-Ring / O-ring 3.00 x 1.00 2
9.2 Beipacks 9.2 Accessories supplied
Beipack PGN-plus 64 / 64 S Accessories supplied PGN-plus 64 / 64 S
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
19 5509 642 Zentrierhülse / Centering sleeve Ø 8 6
35 9611 054 O-Ring / O-ring 3.00 x 1.00 2
Beipack PGN-plus 80 / 80 S Accessories supplied PGN-plus 80 / 80 S
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
19 5509 643 Zentrierhülse / Centering sleeve Ø 10 6
35 9611 112 O-Ring / O-ring 4.00 x 1.50 2
Beipack PGN-plus 100 / 100 S Accessories supplied PGN-plus 100 / 100 S
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
19 5509 644 Zentrierhülse / Centering sleeve Ø 8 2
20 5509 643 Zentrierhülse / Centering sleeve Ø 6 4
35 9611 112 O-Ring / O-ring 4.00 x 1.50 2
Beipack PGN-plus 125 / 125 S Accessories supplied PGN-plus 125 / 125 S
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
19 5509 644 Zentrierhülse / Centering sleeve Ø 12 6
35 9611 112 O-Ring / O-ring 4.00 x 1.50 2
Beipack PGN-plus 160 / 160 S Accessories supplied PGN-plus 160 / 160 S
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
19 5509 645 Zentrierhülse / Centering sleeve Ø 14 2
20 5509 646 Zentrierhülse / Centering sleeve Ø 16 4
35 9611 112 O-Ring / O-ring 4.00 x 1.50 2
Beipack PGN-plus 200 / 200 S Accessories supplied PGN-plus 200 / 200 S
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
19 5509 641 Zentrierhülse / Centering sleeve Ø 6 2
20 5509 640 Zentrierhülse / Centering sleeve Ø 5 4
35 9611 054 O-Ring / O-ring 3.00 x 1.00 2
Beipack PGN-plus 50 / 50 S Accessories supplied PGN-plus 50 / 50 S
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
19 5509 647 Zentrierhülse / Centering sleeve Ø 22 6
35 9611 112 O-Ring / O-ring 4.00 x 1.50 2
Beipack PGN-plus 300 / 300 S Accessories supplied PGN-plus 300 / 300 S

SCHUNK PGN-plus Series Specifications

General

Material	Aluminum, steel
Gripper Type	Parallel Gripper
Repeatability	±0.01 mm
Operating Pressure	2 to 8 bar
Opening Time	0.1-0.5 s
Ambient Temperature	5 °C
