Montage- und Betriebsanleitung für 2-Backen-Parallelgreifer
PGN-plus mit Werkzeugschnittstelle HSK/KM/Capto
Operating manual for 2-Finger Parallel Gripper
PGN-plus with tool interface HSK/KM/Capto
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
12 9937 443 Flachdichtung / Flat seal PGN-plus 64 1
30 9936 629 Quad-Ring / Square ring 21.89 x 2.62 1
31 9610 111 Quad-Ring / Square ring 8.20 x 1.78 1
Dichtsatzliste PGN-plus 64 Ident-Nr. 370 892 Seal kit list PGN-plus 64 Id. No. 370 892
9. Dichtsatz- und Ersatzteilstücklisten
9.1 Dichtsatzlisten
9. Seal kit and spare parts lists
9.1 Seal kit lists
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
12 9937 444 Flachdichtung / Flat seal PGN-plus 80 1
30 9910 063 Quad-Ring / Square ring 29.82 x 2.62 1
31 9610 007 Quad-Ring / Square ring 12.42 x 1.78 1
33 9611 063 O-Ring / O-ring 6.00 x 1.00 1
Dichtsatzliste PGN-plus 80 Ident-Nr. 370 893 Seal kit list PGN-plus 80 Id. No. 370 893
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
30 9610 028 Quad-Ring / Square ring 39.34 x 2.62 1
31 9610 008 Quad-Ring / Square ring 14.00 x 1.78 1
32 9936 628 O-Ring / O-ring 48.00 x 1.00 1
33 9611 063 O-Ring / O-ring 6.00 x 1.00 1
34 9611 163 O-Ring / O-ring 4.00 x 1.00 4
Dichtsatzliste PGN-plus 100 Ident-Nr. 370 894 Seal kit list PGN-plus 100 Id. No. 370 894
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
30 9936 343 Quad-Ring / Square ring 50.47 x 2.62 1
31 9610 018 Quad-Ring / Square ring 16.20 x 2.62 1
32 9935 467 O-Ring / O-ring 60.00 x 1.50 1
33 9611 044 O-Ring / O-ring 10.00 x 1.00 2
34 9611 227 O-Ring / O-ring 5.00 x 1.00 4
Dichtsatzliste PGN-plus 125 Ident-Nr. 370 895 Seal kit list PGN-plus 125 Id. No. 370 895
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
30 9935 921 Quad-Ring / Square ring 66.34 x 2.62 1
31 9610 021 Quad-Ring / Square ring 20.29 x 2.62 1
32 9936 847 O-Ring / O-ring 76.00 x 1.50 1
33 9935 302 O-Ring / O-ring 11.00 x 1.00 2
34 9611 227 O-Ring / O-ring 5.00 x 1.00 4
Dichtsatzliste PGN-plus 160 Ident-Nr. 370 896 Seal kit list PGN-plus 160 Id. No. 370 896
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
30 9610 072 Quad-Ring / Square ring 85.32 x 3.53 1
31 9610 036 Quad-Ring / Square ring 25.00 x 3.53 1
32 9936 043 O-Ring / O-ring 106.00 x 2.00 1
33 9935 303 O-Ring / O-ring 14.00 x 1.00 2
34 9611 227 O-Ring / O-ring 5.00 x 1.00 4
Dichtsatzliste PGN-plus 200 Ident-Nr. 370 897 Seal kit list PGN-plus 200 Id. No. 370 897
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
12 9938 123 Flachdichtung / Flat seal PGN-plus 50 1
30 9610 125 Quad-Ring / Square ring 18.77 x 1.78 1
31 9610 005 Quad-Ring / Square ring 6.07 x 1.78 1
Dichtsatzliste PGN-plus 50 Ident-Nr. 370 891 Seal kit list PGN-plus 50 Id. No. 370 891
Pos. / item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
30 9610 073 Quad-Ring / Square ring 120.25 x 3.53 1
31 9938 273 Quad-Ring / Square ring 29.74 x 3.53 1
32 9937 935 O-Ring / O-ring 140.00 x 2.00 1
33 9611 115 O-Ring / O-ring 18.00 x 1.00 1
34 9611 227 O-Ring / O-ring 5.00 x 1.00 4
Dichtsatzliste PGN-plus 300 Ident-Nr. 370 898 Seal kit list PGN-plus 300 Id. No. 370 898

SCHUNK PGN-plus Series Specifications

General

Material	Aluminum, steel
Gripper Type	Parallel Gripper
Repeatability	±0.01 mm
Operating Pressure	2 to 8 bar
Opening Time	0.1-0.5 s
Ambient Temperature	5 °C
