SCHUNK PWG-S 40 Translation Of The Original Manual

Assembly
18 02.02|PWG-S 40 - 80|en
Gripper open:
1 Set the gripper to OPEN position.
2 Loosen the OPEN attachment screw (3).
3 Carefully push the proximity switch (1) into the bracket until it
touches the control cam.
4 Pull back the proximity switch approx 0.5 mm.
5 Fasten the proximity switch by tightening the attachment
screw (3).
6 Connect the proximity switch
7 Move the gripper into OPEN position and test the function.
Gripper closed:
1 Set the gripper to CLOSED position.
2 Loosen the CLOSED attachment screw (4).
3 Carefully push the proximity switch (2) into the bracket until it
touches the control cam.
4 Pull back the proximity switch approx 0.5 mm.
5 Fasten the proximity switch by tightening the attachment
screw (4).
6 Connect the proximity switch
7 Move the gripper into CLOSED position and test its function.
