Maintenance and Care
02.02|PWG-
S 40
- 80|en
25
Assembly
with assem
bly bolt
Fig.
8
Di
mensio
ns and pu
rpose o
f t
he assembl
y bo
lt
1
Assembly bolt
4
Compression spring
2
Body
5
Cylinder
3
Cylindric
al screws
1
Screw in the assembly bolt
(1) by hand
2
Press the body (2) onto the cylinder (5).
3
Screw in the cylindrical screws (3).
9.5.1
