Maintenance and Care
02.02|PWG-S 40 - 80|en
23
Disassembling the module
Position of the position numbers (ļ 10, Page 26)
WARNING
Risk of injury when the machine/system moves unexpectedly!
Remove the energy supplies.
Make sure that no residual energy remains in the system.
1 Remove the compressed air line.
2 Loosen the set-screws (12).
3 Push out both bolts (6).
4 Pull out the fingers (4) and compensation disks from the side
of the body.
5 Connect the pressure line to the CLOSED connection and apply
air pressure of 6 bar to the gripper.
6 Unscrew the countersunk screw (11) and remove the bar (5).
7 Depressurize the gripper and remove the pressure line.
WARNING
The body (1) is under spring tension.
Risk of injury due to spring forces!
Strictly adhere to the following instructions. Carefully
disassemble the module.
8 Clamp the body (1) and cylinder (2) between "a" and "b".
9 Remove the screws (10).
10 Unclamp slowly until the springs are no longer under tension.
11 Remove the body (1).
12 Pull the piston (3) out of the cylinder (2)
13 Remove all seals according to the sealing kit list.
9.4
