2. Brief description and technical data
3-Jaw-Loading-Gripper Type UFG 26 / 32:
– broad clamping range
– flat design
– high clamping force
– versatile application (e.g. for loading of tooling machines)
– can be retrofitted as a double gripper without problems
– position of installation: application dependant
– stroke control can be continiuously adjusted
– I.D. and O.D. clamping possible
– centrically gripping
Accessories:
– proximity switch
– pressure piece
– top jaws (custom-made solutions available from SCHUNK)
Technical Data:
Page -4-
UFG 26 UFG 32
Actuation: hydraulically hydraulically
Range of operating temperature:
6...60 bars 6...70 bars
Opening stroke:
32 mm / jaw 54 mm / jaw
Gripping force
: at 40 bars 2300 N at 50 bars 5200 N
Gripping force
: at 6 bars 350 N at 6 bars 500 N
Operating temperature:
5 ϒC - 60 ϒC 5 ϒC - 60 ϒC
Oil volume: “open”
34 ccm 87 ccm
Oil volume: “closed”
29 ccm 78 ccm
Opening time:
0.9 sec. 2.1 sec.
Closing time:
0.85 sec. 2.0 sec.
Repeatability
0.05 mm 0.05 mm
