3. Assembly and Connection
3.1 ASSEMBLY
NOTE:
The gripper must be aligned during assembly
since it is not equipped with fixing bores.
3 fastening threads
UFG 26 M 8 x 17
UFG 32 M 8 x 20
3 Fastening bores
for M8 DIN EN ISO 4762
in the plastic bag
Page -5-
