2. Connect the Cables and Install Console Mast on Frame Assembly
NOTICE: Remove the pre-installed hardware(*) from the mast mount. The Frame cable connector (1a) is attached
to the plastic insert in the mast mount. Leave the plastic insert and Frame cable connector in place and
carefully connect the Console Mast cable. Align the clips on the cable connectors and make sure the
connectors lock. Do not cut or pinch the cables.
Align the curved washers so the surface is flush with the Console Mast tube.
*
*
5mm
*
X4
6
1a
To Next Page
