Seada SD-MV-CM41 - Page 27

4K 4x1 Seamless Switcher with Multi-view
Website: www.seada.co.uk 25 / 33 E-mail: sales@seada.co.uk
Command Function
Command & Feedback
Example
#SET_MV_MODE
[PARAM]
Set multiview mode.
[PARAM]=1 ~ 20
1 - 1 WINDOWS Full
2 - 2 WINDOWS PBP
3 - 3 WINDOWS 2U1D
4 - 4 WINDOWS SAME SIZE
5 - 2 WINDOWS PIP LU
6 - 2 WINDOWS PIP LD
7 - 2 WINDOWS PIP RU
8 - 2 WINDOWS PIP RD
9 - 4 WINDOWS PBP 3L1R
10 - 4 WINDOWS PBP 1L3R
11 - 4 WINDOWS PBP 3U1D
12 - 4 WINDOWS PBP 1U3D
13 - 4 WINDOWS PIP 1F3L
14 - 4 WINDOWS PIP 1F3R
15 - 4 WINDOWS PIP 1F3U
16 - 4 WINDOWS PIP 1F3D
17 - USER CONFIG 1
18 - USER CONFIG 2
19 - USER CONFIG 3
20 - USER CONFIG 4
#SET_MV_MODE 1
@MV_MODE 1
#GET_MV_MODE
Get multiview mode
@MV_MODE 1
#GET_STATUS Get the system status
@V1.0.0
@VIDEO
OUT A B C D
IN 1 2 3 4
@AUDIO_SRC 1
@OUTPUT_RES 7
@AUTO_SWITCH 1
@EDID_MODE 1 2
…
#SET_SWAP_SRC Swap input source
@SWAP_SRC
@VIDEO
OUT A B C D
IN 1 2 3 4
@AUDIO_SRC 1
#SET_RESIZE_WIM
Resize display windows.
@RESIZE_WIM
