A.) Unlock and open the Front Door, unplug vendor.
B.) Pull the Vertical Shelf out completely.
C.) Disconnect Wiring Harness.
D.) Push Tabs in both Tracks up, (Fig. 14) and pull Vertical Shelf free.
COMMON QUESTIONS
AND ANSWERS
Q: Coin Validator will not accept coins.
A: Lenses may be dirty.
Coins may be damaged or worn.
Wire Harness may not be connected properly.
Coin Validator may not have power.
Q: Optional Bill Validator will not accept bills.
A: Stacker may be full.
There may not be enough coins in the Coin Validator.
Wire Harness may not be connected properly.
Bill Validator may not have power.
LOCK
Your Elite Beverage Vendor has one Lock, more commonly known as a "T" handle lock. This Lock is different from that of the
Figure 13 Lens Cleaning
Red
Lenses (3)
Clear Lenses
(3)
Lower Housing
Bill Validator
Figure 14 Vertical Shelf Removal
Push Tabs
up and pull
Shelf free
Track
Vertical Shelf
Track
