Seaga JDL-2 COMBO - Product Loading

11JDL V1.0 8 2022
Incorrect
PRODUCT LOADING
Snack Unit
Wide products such as Chip bags etc. are loaded in Tray 1 and Tray 2. Narrow products such as Candy bars are
loaded in Tray 3. See Figures 8a and 8b.
Figure 8a – Loading Product
Correct – load
product between
coils, resng on the
product tray, never
on the boom loop
of the coil.
Incorrect
Coil
Product Tray
Figure 8b – Loading Product
Correct – load product between coils,
resng on the product tray.
Incorrect
