INSTALLATION
Once the machines have been unpacked and placed in their permanent locaon, the electrical connecon and
mechanical connecon must be made. Tools required: Adjustable wrench and Philips screwdriver. For opmal
installaon, follow the order of connecons as outlined below:
1.Mechanical Connecon between Snack and Beverage Units:
The Snack and Beverage units must be screwed together for safety purposes. Two screws are
provided in the white envelope found in the vend area of the Snack unit. Square the fronts and sides
of the Snack and Beverage units. Open the Snack unit door and locate the two holes at the boom of
the unit. Insert both screws and ghten.
2.Electrical Connecon between Snack and Beverage Units and Beverage Display Lighng Connecon:
Cut an opening in the Styrofoam in the upper right (front) corner and save the foam for reinseron.
Open the Beverage unit door and locate the beverage main harness and refrigeraon harnesses. Insert
harnesses through the opening up into the Snack cabinet (Figure 1).
Figure 1 – Installing Refrigeraon Harnesses
Beverage and
Refrigeraon
Harnesses
Insert Beverage
and Refrigeraon
Harnesses
through here
