Seaga JDL-2 COMBO - Loading Beverage Lanes

14JDL V1.0 8 2022
Front of machine
Back of machine
1.) For most boles, place boom of the rst bole against the front of the column. Place the top of the
second bole to the back of the column, facing the boom of the bole with the top of the rst bole. See
Figure 13. Load 12 oz. cans boom to boom in the rst two posions, then top to top in the back posion.
Load 16 oz. cans boom to boom. 20 oz. Gatorade boles are loaded boom to top.
2.) To adjust the rear spacer, grasp rmly and li, freeing the spacer from the slots in the column sides. Move
the rear spacer to the closest slot to the back of the bole or can placed in the rear of the column. Insert the
boom le corner rst. The gap between the rear spacer and the rear bole or can must be less than ½ inch.
The slots are in ½ inch increments to let you adjust for many sizes of products. Lower the rear spacer into the
new posion, making sure the spacer is straight vercally.
3.) Finish loading to the top of the column, making sure the items are perfectly horizontal and not lted or
skewed in the column.
LOADING BEVERAGE LANES
The Product Columns in your machine use an Auger that rotates counterclockwise to drop the beverage into
the Product Bin.
1.) Grasp Locking Tab and slide up to allow Retainer to rotate forward into Load Posion.
Figure 13 – Retainer
Retainer
Locking Tab
