11
12) Crimp the brass swage tube with a
crimping tool or pliers.
14) Attach ball links to the rudder servo
arm and then attach the servo arm to the
rudder servo as shown.
NOTE : Cable is installed crossed “ X”, not
parallel.
13) Cut o excess cable as shown.
15) Attach the aluminum tube to com-
bine two elevator as below pictures.
To Next Page
