10
11) Loop the cable back through the brass
swage tube and pull tight.
10) read cable through the threaded
coupler hole, and back through the brass
swage tube as shown.
6) Cut o excess cable as shown.
7) Mark and use a 1/16 bit to drill the
rudder servo.
9) read cable through brass swage tube.
8) Feed one rudder cable through the pre
installed cable exit tube in the rear of the
fuse toward the front of the fuse. Repeat
for other side.
in CA.
