Seagull Models RV-8 - Motor Box and Engine Mount; Electric Power Conversion

33
Attach the electric motor box to the re-
wall centered with the cross lines drawn
on the electric motor box and rewall.
Using M5x35mm to secure the motor box
to the rewall. Please see pictures below.
4.
6.
7.
5.
Attach the motor to the front of the elec-
tric motor box using four 4mm blind nut,
four M5x35mm hex head bolts to secure
the motor. Please see picture shown.
8.
9.
M5x35mm and washers
10.
