TECHNICAL SPEC:
Applications: Works with all 1996 and later OBDII/EOBD compliant vehicles.
● Scansforcauseof‘EngineMalfunctionLight’(MIL).
● ScansforpendingDTCs.
● Retreivesgeneric(P0,P2,P3&U10)andmanufacturerspecic
 (P1,P3&U1)DTCs.
● TurnsoffMILlight,clearsDTCsandresetsmonitors.
● DisplaysDTCdenitionsonscreen.
● Viewsfreezeframedata.
● DisplaysmonitorandI/Mreadinessstatus.
● Patentedone-clickI/Mreadinessbutton.
● Retrievesvehicleinformation(VIN,CID&CVN).
● SupportsCANandothercurrentEOBDprorcols.
● Supportsthenewextendedsensorlist(SAEJ1979-2007).
● ReadsliveECU/PCMdatastream.
● DisplaysliveO2sensordata.
● Graphingfunctionforlivedata(96on).
● Read,storeandplaybacklivesensordata.
INTRODUCTION:
The ultimate automotive analyser that combines a multimeter, scope, starter test
and EOBD code reader with extended sensor list in one. Fast and easy access
toanyvehicle’sEOBDdiagnosticcodes,establishingcauseofilluminatedengine
checklight(MIL).Featuresbuilt-indatalibrarywithlookupfunctions.Clear,concise
DTCgenericdenitions displayedon screen.CANEnabled toolretrievesgeneric
P0,P2andP3andU0codesforengineemissionsandmanufacturerspecicP1,
P3andU1codes.ReadsanddisplaysliveECU/PCMdatastream,plottingfunctions
graphicallyandstoresfreezeframedata.LivedisplayofO2sensordatawhichcan
bestoredandplayedback.Updateableviaweb-baseddownloadsandwilllinkwitha
PCusingtheUSBcablesupplied.PatentedOne-ClickI/MReadinessbuttontoelim-
inatedrivecycleguesswork.Supportsnewextendedsensorlist(SAEJ19792007),
trouble-shootercodetipsandrepairinformationtoidentifyrootcauseoftheDTC,so
savingtime.Auto-rangingautomotive diagnosticmultimeterwith volts,currentand
resistance.Scopefunctiontovisuallytestcomponentsignals,withtheaddedbenet
ofmaximum/minimumvolts,frequencyanddutycycledisplayed.Startertest
functionallowstestingofthebatteryandchargingsystem.Internalbattery
back-up for off-vehicle data review/analysis. Supplied with test leads in storage
pouch.
