Figure 5.32
5) Press ESC button to return to previous screen.
5.5 Retrieving I/M Readiness Status
I/M Readiness function is used to check the operations of the
Emission System on EOBD compliant vehicles. It is an excellent
function to use prior to having a vehicle inspected for
emissions compliance.
CAUTION - by clearing trouble codes you also clear the readiness
status for the individual emission system readiness tests. In order
to reset these monitors, the vehicle must be driven through a
complete drive cycle with no trouble codes in memory. Times for
reset vary depending on vehicle.
Some latest vehicle models may support two types of I/M
Readiness tests:
A. Since DTCs Cleared - indicates status of the monitors since the
DTCs are erased.
B. This Drive Cycle - indicates status of monitors since the
beginning of the current drive cycle.
An I/M Readiness Status result of “NO” does not necessarily
indicate that the vehicle being tested will fail the state I/M
inspection. For some states, one or more such monitors may be
allowed to be “Not Ready” to pass the emissions inspection.
“OK” -- Indicates that a particular monitor being checked has
completed its diagnostic testing.
……………… ..FUELSYS1……… …….
Fuel System 1 Status
