Figure 5.42
 For CAN-equipped vehicles, test selections can be as below:
Figure 5.43
6) Use the UP/DOWN scroll button to select the desired monitor
from On-Board Mon. Test menu and press the OK button.
7) View test data on screen.
Figure 5.44
On-Board Mon. Test 1/31..
O2 Mon. B1S1
O2 Mon. B1S2
O2 Mon. B1S3
O2 Mon. B1S4
O2 Mon. B2S1
O2 Mon. B2S2
HO2S11 Voltage amplitu 1/36
ID 11
MOD $10
TEST(volts) 400 ?
MIN(volts) 1E1
MAX(volts) -----
STS OK
On-Board Mon. Test
The selected mode is
not supported
Press any key to con..
