Serial lines
The panel connectors for serial port A and B are DB9 female. Pin layout is described
below:
Pin no.
Signal
1
RS-422 TX+
2
RS-232 TXD
3
RS-232 RXD
4
Not in use
5
GND
6
RS-422 TX-
7
Not in use
8
RS-422 RX+
9
RS-422 RX-
Table 2 Serial line pin layout
Special serial cables are supplied with the DGNSS receiver. The cables are
terminated as described below.
DB9 male
Pin number
2 metre cable
DB9 female
Pin number
2
--------------------
2
3
--------------------
3
5
--------------------
5
Table 3 RS-232 data cable layout
DB9 male
Pin number
2 metre cable
Weidmuller
female
Pin number
1
--------------------
2
6
--------------------
1
8
--------------------
5
9
--------------------
4
5
--------------------
3
Table 4 RS-422 data cable layout
Note! Do not use standard RS-232/ RS-422 cables
Note! Serial port settings depending on subscription type
By default the automatic port settings based on subscription type is set to on. Any
manual changes in the port settings, will disable the automatic port configuration
based on subscription type.
