SeaSTAR 3610 USER MANUAL
Issue 2.3 02/11
15
I : IONO
G : GLONASS
V : VBS
R : RAW (SCF)
About
When pressing arrow down in the Signal status page, the Main menu with its main
pages appears.
The About menu shows information about the 3610 DGNSS receiver.
The DGNSS receiver type, serial number and software version are
displayed.
In addition, the subscription expiry date of the DGNSS service is
displayed.
Main Menu
About
The serial number (Sno) of the unit is important when contacting
Fugro SeaSTAR for subscription requests.
SeaSTAR 3610
Sno. 1160579
SeaSTAR 3610
Ver. 2.01.03
SeaSTAR 3610
Subsc.
SeaSTAR 3610
Exp. 4 Oct 2010
SeaSTAR 3610
Reset
Status
When pressing the Enter or the  button from the the Status menu,
the channel status, NTRIP, VBS, Alarms, Position status, GPS time,
corrections output and Antenna power on/off are displayed.
Main Menu
Status
The Channel status page displays DGNSS satellite status. When
selecting a channel status page and using the  and  buttons to
toggle up and down, the satellite ID, service ID, actual frequency,
symbol rate, Uplink status, good and bad counts, last lock time, C/N
and C/N
0
are displayed. The good and bad counts percentages are
displayed from the last 5 minutes of samples.
Status
Channel A
Status
Channel B
