Alarm situations
The 3610 DGNSS receiver has two LED indicators, one green for power indication
and one red for alarm indication. The red LED will be lit continuously or flash if one of
the situations below arises. The LED will be turned off if the situation which activated
the alarm becomes OK, for example if lock on signal, upgrade of software is finished.
The alarm situation will, however, be stored in the Status menu.
Criteria
LED characteristics
Text displayed
No lock on signal
Continuous red
No lock
During software upgrade
Flashing at ⅓ Hz
Antenna voltage failure, output
voltage to the antenna drops
Flashing at ½ Hz
Voltage failure
Not subscribed
Flashing at ½ Hz
Not subscribed
The user must acknowledge the alarm on the display by pressing ESC before the
alarm text disappears and the LED is turned off. The display will return to the page it
displayed before the alarm text was displayed.
If an alarm arises, but the situation becomes OK before the alarm is acknowledged on
the display, there is a timeout on the display so the alarm text disappears after three
minutes and returns to the page it displayed before the alarm was activated. The LED
will, however, continue to flash until pressing ESC.
