SeaSTAR 3610 USER MANUAL
Issue 2.3 02/11
10
The table below describes the automatic serial port configuration, depending on the
type of subscription:
Subscription type
Serial port A
Serial port B
H : HP
X
L : L1
X
I : IONO
X
G : GLONASS
X
V : VBS
X
R : RAW (SCF)
X
UDP ports
The Ethernet connector is a standard RJ45 Ethernet connector with two LEDs.
Shielded Ethernet cables can be used to connect to this port.
The Ethernet interface provides the possibility to send corrections on four different
UDP ports.
Default port numbers are:
A: 31100
B : 31110
C : 31120
D : 31130
Default UDP Net Mask is:
: 192.168.000.255
The UDP port mask must be configured to match the Ethernet to which it is connected
to. Activation of the ports to be used must also be configured, by default all UDP ports
are set to off. Type of correction output on the UDP ports is configured in the Port Cfg
menu, under each UDP port.
