Secomea SiteManager 1439 - Default Chapter; Table of Contents

SiteManager xx29/xx39 - Working with I/O ports Page 2 of 12
Version 2, April 2013
Table of Contents
Introduction 3
1.
About GND, 0V GND and Shield 3
2.
Digital Input Ports 4
2.1. Electrical information 4
2.2. Input ports default functionality 4
2.3. Low-side Output switching equipment example 4
2.4. High-side Output switching equipment example 5
2.5. Changing Input 1 default functionality 5
2.6. Defining an Input port Email alert on the GateManager 6
2.7. Defining an Input port SMS alert on a SiteManager xx39 7
3.
Digital Output Ports 8
3.1. Electrical information 8
3.2. Output ports default functionality 8
3.3. Low-side Input switching equipment example. 9
3.4. High-side Input switching equipment example. 10
3.5. Changing Output 2 default functionality 11
Notices 12
