SECOP 101N08 Series User Manual

29
Operating
Instructions
Parameter
Group
Parameter text Description Default Min
value
Max
value
Step
size
Unit Type
Main functions Compressor 2
Reset power con-
sumption
Resets cumulative power consumption
of Compressor 2 to zero
0 0 1 1
0 = OFF
1 = ON
Setting
Total power con-
sumption
Cumulative power consumption of
Compressor 2
0 65535 10 W
Measure-
ment
Total power con-
sumption since start
Cumulative power consumption of
Compressor 2 since the most recent
startup
0 65535 10 Wh
Measure-
ment
Total power con-
sumption last period
Cumulative power consumption of
Compressor 2 in the previous period
0 65535 10 Wh
Measure-
ment
Battery protection
12 V DC Battery cutout level Battery protection cut-out voltage level 10.4 9.6 17 0.1 V Setting
Battery cutin diff. Battery protection cut-in 1.3 0.5 10 0.1 V Setting
24 V DC Battery cutout level
Battery protection cut-out
voltage level
21.3 19.0 27.0 0.1 V Setting
Cutout delay
Time to cut-out when non-critical
battery protection implemented
3 0 60 1 sec Setting
Cut-in level
Calculated value.
Cut-in = Cut-out + Diff
V
Measure-
ment
Supply voltage
Real time voltage
measured on + and - terminals
V
Measure-
ment
Compressor 1
Requested speed
Compressor speed and therefore cap-
city definition
4000 2500 4000 1 rpm Setting
Start delay
Time to start after compressor is swit-
ched ON
4 2 240 1 sec Setting
Start Speed
Optional startup speed lower than
Requested speed, during the period
Start time
2500 2500 4000 100 rpm Setting
Start time
Period of time elapsing after startup
of compressor until Requested speed
is reached
30 0 600 5 sec Setting
Compressor speed Real-time speed (+/- 10%) 100 rpm
Measure-
ment
Supply voltage
Real time voltage
measured on + and - terminals
V
Measure-
ment
