Using the Configurator

Note: The Tools menu is only available if you checked the Show Tools Menu option. See

User Preferences.

External Bus

Toggles the "Use External Bus" setting. When turned on,

this signals that the configurator is connected to the

External Bus of the panel.

Table 33 Tools Menu (Continued)
