Hardware Layouts

11.9 BBX-MNSXP Multi-Purpose Backbox

This backbox can provide additional audio amplification for speakers and strobes. It can hold

up to 7 amplifier boards and 3 INX-10AC Intelligent NAC Expander/Power Supplies. The outer

dimensions are 62.75” X 27.5” X 9”.

Figure 59 Audio System Installation into BBX-MNSXP with CH-993B Internal

Chassis

Note: Leave bottom of box conduit free for batteries.

QBC-5000N

QMB-5000B

QPS-5000N

INX-10AC

(RB-MD-950)

BATTERIES

Rail for mounting

up to 9 Addressable

Modules

10 AWG Tinned Copper

Ground Strap
