Hardware Layouts

Note that the deadfront and door can be installed such that they open either to the left or to the

right as required. The outer dimensions of the MMX-LOC fit within 25.0” X 15.0” X 7.0”.

Figure 61 MMX-LOC

IM-10

Input Module

RAXN-LCD

LCD Network

Annunciator

QMP-5101N

Network Paging

Microphone

FDS-008

Fan/Damper

Switching Module

Default Chapter3
