Secutron MR-2200 - Control Unit Service Screens Continued

64
Appendix C: Service Terminal
85 Alarms
For a single circuit, shows a grid displaying the current Alarm,
Early Warning, Supervisory and Trouble conditions for all devices
on the circuit.
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
86 Function
For a single circuit, shows a grid displaying the Alarm and
Supervisory initiating devices. Control modules are neither type
and are displayed as a dash (-).
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
88 Control Modules
For a single circuit, shows a grid displaying the current status of
all the Control modules.
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
89 Bypass & Test
Displays the Bypass and Test status of all devices on an
addressable circuit.
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
Screen Name Description
