63
Appendix C: Service Terminal
82 Type On-Line
For a single circuit, shows a grid displaying all the devices that
are actually on the circuit.
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
83 Type Assigned
For a single circuit, shows a grid displaying all the devices that
are programmed to be on the circuit.
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
84* Errors
For a single circuit, shows a grid displaying all the incorrect,
missing and mismatched devices. This shows the differences
between what is expected to be on the circuit and what actually is
on the circuit.
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
Screen Name Description
