62
Appendix C: Service Terminal
49 Clock
Shows the status of the Daylight Savings Time option & clock
calibration.
50 Tasks
This screen is restricted to Privilege Level 1 and above. This
screen is for factory use only.
51* FIFO
This screen is restricted to Privilege Level 1 and above. Displays
the FIFO memory usage of various system tasks. This diagnostic
screen needs to be consulted if the panel has a Memory
Overflow trouble. The first line shows the total FIFO space and
the largest amount any one task has used. For each task, the first
number is the current usage and the second is the maximum
usage. If a task uses a large amount of FIFO memory, this means
that task is having difficulty in operating.
52 Memory
Displays the type and amount of extended memory installed in
the system.
61
Local
Annunciator
Displays the states of the optional LED zones on the front panel.
68*
Remote
Terminal
Displays the service terminal screens for another panel in the
network. This allows for the trouble shooting of a system from a
single location. This screen automatically disconnects the remote
connection if memory gets low or if no communication is received
for 15 seconds. The remote panel stops sending data after 15
minutes.
Commands
(id) N Display the service terminal for Panel id
<Esc> Disconnect remote connection
69* Network Verify Displays the current status of the network verify feature.
79
Addressable
Info
System Settings regarding addressable settings.
80* Totals
Displays totals for both SLCs, including items such as assigned,
on-line, missing, etc. Also lists the total number of devices in
alarm, supervisory or trouble conditions. Also lists current wiring
supervision status for each loop.
81* Detail
For a single device, shows all the programming, analog values,
status and commands sent.
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
Screen Name Description
