If it is still not working, please use new JVS cable.

Display

Error 6402

JVS I/O board does not fulfill the game spec

Reason

The I/O board is not correctly used.

Solution

Please use JVS I/O board which fulfills the game spec.

● PROGRAM SPECIFIC

Display

Error 1000

Wrong Coin Setting

Reason

Coin setting is independent, not common.

Solution

Change coin setting to common.
