www.seuservice.com
48
VALVE TEST
This test allows the functioning of each Air Valve, Limit SW and Volume to be checked.
Performing settings while riding on the Ride is dangerous as the Ride moves. Use
the Start button instead of Test button, and the View button instead of Service
button.
VALVE TEST
> PITCH VALVE & ETR CHECK
ROLL VALVE & ETR CHECK
EXIT
PRESS TEST BUTTON TO EXIT
FIG. 9. 3 f a VALVE TEST Screen
FIG. 9. 3 f b VALVE Arrangement
FIG. 9. 3 f c LIMIT SW Arrangement
To Next Page
