Sekonic C-800 User Manual

114
6. Measurement Tool [Tool Box] Screen
No.
Display Mode
Icon
Part Name Description
1
Memory Recall Mode
[Text] Icon
Displays user-selected 5 items in numeric values.
(
P34)
2
Memory Recall Mode
[Spectrum] Icon
Displays 3 user-selected values and spectrum
distribution graph. (
P37)
3
Memory Recall Mode
[CRI] Icon
Displays the selected average CRI (Ra) or
individual CRI (R1 ~ R15) numerically. Each CRI
is displayed in a graph. (
P43)
4
Memory Recall Mode Displays four current measurement values (Rf, Rg,
CCT,
uv) and color vector graphic. ( P49)
5
Memory Recall Mode
Compares the current measurement value and up
to 2 reference values (color temperature and
uv), and displays SSI index with the SSI spectrum
graph. (
P51)
6
Memory Recall Mode
Displays the current measurement values and
memorized values (in color temperature and
uv), TLCI and TLMF with spectrum graph.
(
P62)
7
Memory Recall Mode
names required to adjust measured source to
Target Color temperature. (
P70)
8
Memory Recall Mode
[Lighting Filter] Icon
required to adjust measured source to Target
Color temperature. (
P66)
9
Memory Recall Mode
[WB Corr.] Icon
Displays correction values in LB index and CC
index between the current measurement value
and the target color temperature in a white
balance graph. (
P81)
The contents of Memory Recall Mode display the selected display items in the current
Display Modes instead of display items at the time when memorized.

Sekonic C-800 Specifications

General

Dimensions (WxDxH)	73 x 183 x 27 mm
Interface	USB 2.0
USB powered	Yes

Weight and Dimensions

Weight	230 g
